Specifications:
Combinating Keyed Alike
Deadbolt 1-1/8″ x 2-1/4″ Faceplate Drive-In Ring
Door Prep 1″ x 2-1/8″
Door Thickness 1-3/8″ x 1-3/4″
Function Double Cylinder Deadbolt
Grade Grade 2 – Medium Duty Commercial / Heavy Duty Residential
Handing Field Reversible
Included in package Instructions Template Mounting Hardware
Industry Finish US10B/613 Dark Bronze
Keyway Schlage C123
Latch/Bolt/Backset Adjustable
Manufacturer Schlage
Material Brass Steel
Pinning 6-Pin
Reinforcement Anti-Pry Shield
Series B500
Standards / Ratings UL ANSI A156.2
Strike 1-1/8″ x 2-3/4″
Trim Ring No
Type – Additional Info Cylindrical
For more information, Connect With Us and let IDN help find what you need.
Applications:
Deadbolts provide additional security for many applications. Deadbolts offer a longer locking bolt which extends farther than most latches. The bolt can only be retracted with the proper key or combination or by means of a Thumbturn.
