1200lbs Magnalock, Face Drilled, Gate Conduit, 12/24VDC, Weather Resistant, Grade 2, UL, 630/US32D Satin Stainless Steel

Securitron

The M62 is a strong, easy-to maintain solution for interior, perimeter and exterior access control. With unsurpassed durability, the M62 will last long after most buildings wear out. Flexible mounting options support applications for hollow metal, concrete filled metal, wood, or glass with aluminum frames, and Herculite doors. Options include single and double door configurations, or specialty applications such as gates and fences.

Features:

• PoE friendly
• Fire rated—3 hours
• Sustainability documentation
• Automatic dual voltage – no field adjustment required
• Fully sealed electronics – tamp and weather resistant
• Size optimized for use with door closers
• All ferrous metal surfaces plated to MIL specification
• Patented instant release circuit – no residual magnetism
• Noise suppression with built-in MOV
• Ten feet [3.05m] of jacketed, stranded conductor
• Ultra-secure collapsing blind nuts mount to door frame for strength and reliability
• MagnaCare lifetime replacement, no-fault, no questions asked warranty
• F- Face drilled
• G- Gate conduit
• B Patented BondSTAT magnetic bond sensor
• D- Integrated door position switch (DPS)
• SS- Split strike available
• SASM- Shock absorbing strike mount for gates
• OS- Offset strike
• EX- UL Certified for hazardous locations. Note: Only available with “G” configurations (e.g. M62G-EX)

Specifications:

• Maximum Operating Temperature (°F): 140
• Minimum Operating Temperature (°F): -40
• Outdoor Rated: Yes
• Fire Rated: Yes
• Fire Rating (hrs.): 3
• Preload Capable: Yes
• Current 12v DC (mA): 250
• Current 24v DC (mA): 150
• Voltage: 12/24
• Certifications: ANSI/BHMA A156.23, Grade 2
• Holding Force (lbs): 1200
• Magnet Depth (in): 2.75
• Magnet Height (in): 3
• Magnet Length (in): 8
