90 Degree Offset Pull x Push Bar, 10in CTC x 33in CTC, 1in Diameter Round, 2-1/2in Clearance, Decorative Blind Thru Bolt NO Mount, ADA Compliant, BLK Matte Black

Ives

Ives offers a comprehensive range of architectural push bars and pull/push bar combos designed to meet the needs of any project, regardless of the door’s design, size, type, or location. The 9100 series are tested to withstand high-traffic areas and abuse. Whether you need a straight or offset pull/push bar combo, Ives has a reliable and durable solution. The 9100 series push bars and pull/push bar combos are designed to provide robust support and a sleek appearance for doors in high-traffic areas. These products are available in various sizes and finishes, ensuring that there is a perfect match for every door. Made from high-quality materials like brass and stainless steel, these push bars and combos offer durability and performance, making them suitable for both internal and external applications.

Specifications:

• Meets ANSI/BHMA 156.06 standards
• Made from brass or stainless steel
• Designed to withstand high-traffic areas and heavy use
• Ideal for both internal and external applications
• Models available in various sizes, finishes, offset styles, and substrates
• Line includes Ives ADA-compliant pulls (EZ) that have a door-to-pull clearance of 2-1/2″ or greater
• EZ pulls come standard with 316 series stainless, which makes them highly recommended for all external applications
• Heavy-duty mounting hardware exceeds industry standards
• Suitable for various door thicknesses with optional mounting hardware available

Models:

• 9100HD: Solid push bar
• Available Sizes: Standard lengths of 28″ and 33″; also available in whole 1″ increments from 25″ to 45″
• Dimensions: Projection 2-1⁄2″, clearance 1-1⁄2″, center to center 25-45″, add 1″ to CTC length
• 9103EZHD: Solid straight pull/push bar combo (8103EZHD pull + 9100HD push)
• Available Sizes: Standard lengths of 28″ and 33″; also available in whole 1″ increments from 25″ to 45″
• Dimensions: CTC push 25 to 45″, projection push and pull 2-1⁄2″ and 3-1⁄2″
• 9145EZHD: Solid 45° offset pull/push bar combo (8145HD pull + 9100HD push)
• Available Sizes: Standard lengths of 28″ and 33″; also available in whole 1″ increments from 25″ to 45″
• Dimensions: CTC push 25 to 45″, projection push and pull 2-1⁄2″ and 3-1⁄2″
• 9190HD: Solid 90° offset pull/push bar combo (8190HD pull + 9100HD push)
• Available Sizes: Standard lengths of 28″ and 33″; also available in whole 1″ increments from 25″ to 45″
• Dimensions: CTC push 25 to 45″, CTC pull 8″, projection push and pull 2-1⁄2″ and 3-1⁄4″
• 9190EZHD: Solid 90° offset pull/push bar combo (8190EZHD pull + 9100HD push)
• Available Sizes: Standard lengths of 28″ and 33″; also available in whole 1″ increments from 25″ to 45″
• Dimensions: CTC push 25 to 45″, CTC pull 8″, projection push and pull 2-1⁄2″ and 3-1⁄2″

Specifications:

• Material: Made from brass or stainless steel (304 or 316 series)
• Heavy-duty mounting hardware exceeds industry standards
• Certifications: Meets ANSI/BHMA 156.06 standards
• Comes standard with type NS mounting
• Compliance: ADA compliant models available for 9103EZHD, 9145EZHD, 9190EZHD pull and push bar combos
• Available with through bolt screws and decorative washers (STD – mount)
• Optional mounting hardware available
• Specify door thickness; standard for 1-1⁄2″ to 1-3⁄4″, optional for 2″ and 2-1⁄4″ thick doors

Finishes:

• US3/605 – Bright brass
• US4/606 – Satin brass
• US10/612 – Satin bronze
• US10B/613 – Oil rubbed bronze
• US15/619 – Satin nickel
• US26/625 – Bright chrome
• US26D/626 – Satin chrome
• US28/628 – Satin aluminum, clear anodized
• US32/629 – Bright stainless
• US32D/630 – Satin stainless
• BLK/631 – Matte black
• 643e/716/643e/716 – Aged bronze
• SP313/US10BE/695 – Dark bronze powder coat
