Mullion Bottom Fitting, 600/USP Prime Coated

Precision Hardware

The mullion is used to adapt a double door opening to two single door openings with Rim exit devices. When the full width of an opening is required, the mullion may be removed.

Features:

• Key Removable Mullion (KR): Provides a secure yet quick & easy means of removing the 822 or FL822 mullion. The mullion can be reinstalled and locked without the need of the key.
• Stock Size: For openings 8’-0” high. For openings less than 8’-0” high the mullion can be cut down. For openings greater than 8’-0” high using the 822, KR822 or 811 mullions
• U.L. Listed: FL822 and FLKR822 listed for fire exit hardware.
• Mullion: 2” x 3” Steel.
• Mullion Base: Investment cast steel, 2” wide 3-1/2” deep. Furnished with steel anchors for concrete floors
• Interlock: Black powder coated investment cast stainless steel. Furnished standard for FL822 and FLKR822 mullions. It interlocks the mullion to the rim active case and S300 or S301 strike.
• Stabilizers: Black powder coated steel. Stabilizers are furnished standard for FL822 and FLKR822 mullions.
• Mullion Cap Spacer: Minimum width 3-1/2”. For 2-1/4” frame spacer specify part No. MCS822. For use with 822 series mullion only (e.g. 822, FL822, HC822, HCKR822, KR822, FLKR822). MCS822 Kit or 822 mullion suffix option.
• 822, FL822 Mullion Cap: MC822 Investment cast steel, 4” wide 3-5/8” deep.
• KR822, FLKR822 Key Removable Mullion Cap Assembly: Investment Cast Steel – can be ordered to convert existing 822 or FL822 mullions to keyed removable mullions. Retrofits to the hole pattern of an MC822 mullion cap.
• KR822, FLKR822, HCKR822 Mullion Storage Kit: Set of top and bottom mounting brackets enabling secure storage. Kit includes: 1 ea. KMC822 Top fitting (less rim cylinder), 1 ea. MB822 Bottom fitting and 1 ea. AB822SK Top fitting angle bracket.

Finishes:

• 600 – Primed for paint
• 689 – Aluminum paint
• 695 – Dark bronze paint
