3/4in Offset Pivot Set, Left Handed, Standard-Duty, Up to 600lbs, Door Width up to 48in, BSP Black Suede Powder Coat

Rixson

The 147 is an offset-hung, standard-duty pivot set designed for interior or exterior doors weighing up to 600lbs.

Features:

• Exterior or interior doors
• Weight up to 600lbs. (door size & weight guidelines are determined using the appropriate number of intermediate pivots)
• Door width up to 4’0″ (1219mm)
• Handed
• 180 top pivot included; M19 intermediate pivot required (sold separately)
• Bottom pivot mounts directly to floor
• 3/4″ (19mm) offset (measured from centerline of pivot to face of door)
• Door edges must be beveled 1/8″ in 2″
• Doors will swing 180°, trim permitting
• Uses same arm and cap as 27 floor closer
• Non-ferrous base material
• Doors 60″ (1524mm) to 90″ (2286mm) in height should use one intermediate pivot – each additional 30″ (762mm) of door height warrants another intermediate pivot
• Available for 1-1/2″ (38mm) offset (door weight 350 lbs.) for doors with cladding or frame molding
• Furnished with wood and machine screws
• Available with extended spindles in 1/2″ (13mm) increments up to 2″ (51mm) longer than standard

Specifications:

• Hang Type: Offset hung
• Maximum Door Weight: 600 lbs
• Warranty: 2-year limited warranty
• ANSI/BHMA A156.4, grade 2

Finishes:

• 605/US3 – Bright brass, clear coated
• 611/US9 – Bright bronze, clear coated
• 612/US10 – Satin bronze, clear coated
• 613/US10B – Antique bronze
• 613E/US10BE – Dark oxidized satin bronze-equivalent coated
• 618/US14 – Bright nickel plated, clear coated
• 619/US15 – Satin nickel plated, clear coated
• 622/US19 – Flat black coated
• 625/US26 – Bright plated chrome
• 626/US26D – Satin plated chrome
• BSP – Black suede powder coat
• WSP – White suede powder coat
