Gate Electric Strike, for Use with Rim Exit Devices, 12VDC, Field Selectable FS or FSE, 4-7/8in x 1-1/4in Faceplate, up to 1in Throw, Right Hand Field Reversible, Satin Stainless Steel, Centered Cavity

Trine Access Technology

For new or replacement installations in wood or metal jambs. Use with cylindrical locksets, mortise locks without dead bolts, and mortise exit devices with up to 7/8″ throw.

Features:

• Superior strength – 2,000+ lbs UL® tested.
• Superior life – durability of 1,000,000+ life cycles
• Superior Application – outdoor UL rating allows the strike to be used anywhere – especially good for gates.
• Fail secure/fail safe field reversible on DC units.
• Grade 1 strike – contains a one piece locking mechanism with one solenoid – less parts mean less problems.
• Left and right handing is field reversible.
• Great for all high humidity environments like at marinas and pools. The go anywhere strike!

Specifications:

• UL® Listed 10C – fire-rated – class A, 3-hour, single swing door
• UL® Listed 1034 – Indoor/outdoor burglary resistant
• BHMA 156.31 2001, grade 1
• NYC MEA 79-01-E

EN Series Electrical Characteristics:

• Volts: 12AC
• Current: 0.700
• Ohms (Ω): 4.5
• Duty: Into.
• Sound: Buzz
• Wire: 1-Blue, 1-Orange/White
• Volts: 24AC
• Current: 0.370
• Ohms (Ω): 18.0
• Duty: Into.
• Sound: Buzz
• Wire: 1-Blue, 1-Black/White
• Volts: 12DC
• Current: 0.280
• Ohms (Ω): 43.0
• Duty: Into./Cont.
• Sound: Silent
• Wire: 2-Orange/White
• Volts: 24DC
• Current: 0.150
• Ohms (Ω): 164.0
• Duty: Into./Cont.
• Sound: Silent
• Wire: 2-Black/White

Finishes:

• 32D/630 – Satin stainless steel
• 10B/613 – Dark bronze
• US3/605 – Bright brass
• US4/606 – Satin brass
• 10/612 – Satin bronze
• 32/629 – Stainless steel
• BLK – Black powder coat
