The 100-Series door knobs feature cylindrical construction for use on a variety of commercial doors. Classic Ball (B) and Plymouth (P) styles make these excellent retrofit and replacement locks.
Specifications:
Design Style Plymouth (P) Flattened Round
Door Prep 2-1/8″ diameter cross bore; 1″ edge bore
Door Thickness 1-3/8″ – 1-3/4″
Function Passage
Grade Grade 2 – Medium Duty Commercial / Heavy Duty Residential
Handing Field Reversible
Included in package Installation Instructions
Industry Finish US32D/630 Satin Stainless Steel
Knob/Lever Knob
Latch/Bolt/Backset 2-3/8″
Manufacturer LSDA
Series 100
Standards / Ratings ANSI/BHMA Grade 2
Strike ASA 4-7/8″
Type – Additional Info Cylindrical
For more information, Connect With Us and let IDN help find what you need.
Applications:
These locks are recommended for use on exterior and interior doors. Typical applications include Offices, Commercial Properties, Retail Spaces, and Multi-Family Buildings.
LSDA GRADE 2 PASSAGE KNOB PLYMOUTH 2-3/8″ STAINLESS STEEL 028535 – 110P32D2-3/8
